BG Masterplug TMIHDIG Digital Weekly Immersion Timer with LED Indicators/Boost Button
The BG Masterplug TMIHDIG-MP Digital Weekly Immersion Timer with LED Indicator/Boost Button is a time control unit for 16amp hardwired appliances. ideal for immersion heaters. with manual override and power indication
FEATURES
• General purpose timer to offer complete control
• Ideal for immersion heaters, towel rails and lighting
• Battery back up in event of power failure
• Large display screen with LED backlight
• 24 hour, 7 day control, 4 programmes
• Power and operation LED indicators
• Boost button
• Cable grip
• Two fixing points
• Easy to install, complete with instructions
PRODUCT INFORMATION
Part Number: TMIHDIG
Product Dimensions: Height 121.5mm x Width 73.5mm x Depth 40mm
Standard(s): This product is certified to applicable British safety standards
EN60730-2-7
Operating Temperature: 0°C to 40°C
Rating: 16(2)A 240V~, 50Hz
Operating Time: Continuous
Maximum Load : 16(2)A, 3,840 Watts (2AX Inductive Load)
Switch Type : 16A relay
Terminal Capacity: 1.5mm² – 2.5mm² Flexible Cable
Time Period: 7 day
Pollution Degree: 2
Power ON Light: Yes
Output Light: Yes
Rated Impulse Voltage: 4KV
Temperature of Ball Pressure Test: Category D
Accuracy: ± 1 Minute/Mon
Backup Battery: NiMH1.2V>100hrs
